8T Stainless Steel Tubular Type UHT Juice Pasteurizer
Product Description
Specifications
1. Material : SUS304/316
2. Capacity/Flow: 1~20T/H
3. Motor power: 1.9-11KW
4. quick sterilizing for food fluid
Introduction of tubular sterilizer:
UHT high temperature instantaneous sterilizer is widely used in the sterilization of milk, fruit juice, tea drinks and other products. UHT sterilizer integrates heating, sterilization, cooling and heat recovery. The touch screen displays real-time production data online. This equipment is suitable for continuous sterilization of fruit and vegetable juice, tea beverage, milk beverage or similar materials. It can carry out high-temperature instantaneous sterilization of materials and rapid sterilization in a very short time, so as to ensure that the nutritional components of materials are not damaged and lost, and the product color is not changed.
The main body of HT high temperature instantaneous sterilizer is divided into: hot and cold material heat recovery section, preheating section, sterilization temperature holding section and cooling section. The whole sterilization process is fully automatic control, and the sterilization temperature can be flexibly set on the man-machine interface. The fluctuation of temperature difference between upper and lower sterilization temperature during production shall not exceed 0.5 ℃ Equipped with pressure multifunctional tank, it can buffer material and material reflux during production, and can be used as CIP cleaning tank after production.
|
Capacity (t/h) |
Steam Consumption (kg/h) |
Steam Pressure (bar) |
Power (kw) |
Dimension (L*W*H) |
Weight (kg) |
|
1 |
130 |
2.5 |
1.9 |
3.3×1.6×1.8 |
1490 |
|
2 |
260 |
2.5 |
2.1 |
3.3×1.6×1.8 |
1590 |
|
3 |
390 |
2.5 |
3.0 |
3.5×1.8×2.0 |
1630 |
|
4 |
520 |
2.5 |
3.0 |
3.5×1.8×2.0 |
1870 |
|
5 |
650 |
2.5 |
3.0 |
3.5×1.8×2.0 |
2060 |
|
6 |
780 |
2.5 |
3.0 |
3.5×1.8×2.0 |
2250 |
|
8 |
1040 |
2.5 |
3.7 |
4.5×2.0×2.0 |
2500 |
|
10 |
1300 |
2.5 |
5.2 |
4.5×2.0×2.0 |
2800 |
|
15 |
1950 |
2.5 |
7.0 |
6.5×2.0×2.2 |
3500 |
|
20 |
2600 |
2.5 |
11.0 |
6.5×2.0×2.2 |
4300 |
Machinery detailes
